Boss TU-3W WAZA Chromatic Tuner
The TU-3W brings Waza Craft mojo to the world’s leading stompbox tuner platform. This high-performance pedal combines the trusted tuning features of the TU-3 with selectable buffered/true bypass operation and refined circuitry for the most transparent audio pass-through possible. Built for discriminating players, the TU-3W delivers a premium pedal experience only available from BOSS.
| Battery Life: Alkaline: Approx. 5.5 hours, Carbon: Approx. 0.5 hours (These figures will vary depending on the actual conditions of use.) |
| Brand: Boss |
| Bypass: Buffered bypass or True bypass |
| Connectors: INPUT jack: 1/4-inch phone type, OUTPUT jack: 1/4-inch phone type, BYPASS jack: 1/4-inch phone type, DC IN jack, DC OUT jack |
| Controls: Pedal switch, OUTPUT switch (BUF/THRU SW), MODE button, STREAM/CENT button |
| Current Draw: 50 mA (DC 9 V), 110 mA (DC 9 V, when High Brightness mode is on) |
| Depth: 5-1/8 inches |
| Height: 2-3/8 inches |
| Included Accessories: Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information"), Alkaline battery (9V, 6LR61) |
| Indicator: CHECK indicator (Serves also as battery check indicator) |
| Input Impedance: 1 M ohm |
| Nominal Input Level: -20 dBu |
| Nominal Output Level: -20 dBu |
| Options (sold separately): AC adaptor: PSA series, Parallel DC cord: PCS-20A (DC Plug x8) (sold separately) |
| Output Impedance: 1 k ohm |
| Power Supply: Alkaline battery (9V, 6F22) or Carbon-zinc battery (9V, 6LR61), AC adaptor (sold separately) |
| Recommended Load Impedance: 10 k ohms or greater |
| Reference Pitch: A4 = 436--445 Hz (1 Hz step) |
| Tuning Accuracy: +/- 1 cent |
| Tuning Range: C0 (16.35 Hz)--C8 (4,186 Hz) |
| Weight: 460 g, 1 lb 1 oz (including battery) |
| Width: 2-7/8 inches |
